[en] Control Options

[en] Expansion Port Options

Lumenradio CRMX

[en] 5-pin XLR and RJ-45

[en] sACN & Art-Net

[en] Lumen CRMX & BLE

[en] Comms Modules

[en] Comms Modules plug into the expansion port on the back of the Astra IP for additional control options. There are two versions of Comms Modules which provide additional input options.

[en] DMX Comms Module adds 5-Pin XLR and RJ45 In and Out ports. The ports are passive, which means DMX will flow through the module even if the light is off. See the DMX module >Here<.

[en] DMX Comms Plus provides networking protocols in addition to wired DMX input. Receive sACN & ArtNet on the RJ45 ports which act as a 2-port switch. This module also includes Lumenradio's TimoTwo chip for Wireless DMX and CRMX BLE protocols.
